Hissco International — HS6040 EVO2
Mail and Small Parcel · Model brochure & technical specifications
Compare HS6040 EVO2 against 209 other scanners
Full specs on this page are free to view. Register free to save comparisons and unlock the brochure PDF.
Open X-Compare
Brochure PDF locked
Login to preview the full document.
Login to unlock
Tunnel
Tunnel Width (mm)
610
Tunnel Height (mm)
410
Conveyor
Conveyor Height (mm)
660
Conveyor Speed (m/s)
0.20
Load Capacity (kg)
200
Generator
X-ray Voltage (kV)
160
X-ray Current (mA)
1.2
Generator(s)
1
Imaging
View(s)
Single
Performance
Image Resolution (lp/mm)
N/A
Wire Resolution (mm)
42
Steel Penetration (mm)
38
Generator
Cooling Type
Sealed oil cooling
Mechanical
Footprint (L×W×H) (mm)
1873 x 858 x 1256
Weight (kg)
355
Electrical
Power
AC 220V (± to 10%) 50 Hz / 60 Hz ± 3 Hz 0.5 kVA
Software
Software / OS
N/A
Options
Options
• TIP - Threat Image Projection • AI (Assisted Imaging)™ Item Recognition • Roller tables (entry/exit) built to any length • UPS (Uninterrupted Power Supply) Touch Screen Interface 21” Monitor Tunnel Guards Extended Belt Speed to 0.50 M/S
Features
Features (9)
- 5 Years X-Ray Generator Warranty
- CIRTS (Computer Item Recognition Training Software)
- Compact design
- Ultra-thin object scanning using micro photo sensors
- Self Diagnostics
- Organic / Inorganic Stripping (Material Discrimination)
- Automatic threat and density alert
- Network ready
- Image archiving
