Rapiscan — 922DX
Checkpoint · Model brochure & technical specifications
Compare 922DX against 209 other scanners
Full specs on this page are free to view. Register free to save comparisons and unlock the brochure PDF.
Open X-Compare
Brochure PDF locked
Login to preview the full document.
Login to unlock
Tunnel
Tunnel Width (mm)
770
Tunnel Height (mm)
570
Conveyor
Conveyor Height (mm)
850
Conveyor Speed (m/s)
0.2 + 0.35 + 0.5
Load Capacity (kg)
165
Generator
X-ray Voltage (kV)
160
X-ray Current (mA)
N/A
Generator(s)
2
Imaging
View(s)
Dual-View
Performance
Image Resolution (lp/mm)
N/A
Wire Resolution (mm)
42
Steel Penetration (mm)
39
Generator
Cooling Type
Sealed oil bath with forced air
Mechanical
Footprint (L×W×H) (mm)
2450 x 1616 x 1566
Weight (kg)
1556
Electrical
Power
115/230 VAC ±10%, 60/50Hz
Software
Software / OS
Windows OS
Options
Options
SCANOS 64-bit Operating System Geometric Distortion CORRECTION Classic 4 color, Spectrum 4 & Spectrum 7 SINERGY low density enhancement Dual Mode Z-effective Crystal Clear™ VOLUMIZER Automatic, Enhanced Image Archiving Multilingual Support
Features
Features (0)
N/A
